Sensores industriales y robustos, con distintas funcionalidades y protocolos.
ER-Soft

Sensores industriales y robustos, con distintas funcionalidades y protocolos.


Sensores industriales y robustos, con distintas funcionalidades y protocolos. Con WiFi y web Server muy versátiles para distintos entornos.


PAPOUCH
 AD4USB - USB A-D measurement module

Código: AD4USB_U

AD4USB measuring converter is a 4-input A/D converter which enables the user to measure to four current inputs ranging from 0(4) to 20 mA or voltage between 0 and 10 V. The measured values are then transferred to a superior system in digital form. The AD4
  • Four analogue inputs for voltage or current
  • Each channel can have different range (upon request)
  • Measuring range split into 10 000 pieces
  • Mesuring rate: twice in a second for each channel
  • Communication via USB
  • Spinel and Modbus RTU communication protocols (MODBUS documentation on request).
  • Measuring software for watching and logging is supplied as a freeware
  • Measuring is based on a single multiplexed 16 bit sigma-delta A/D converter

AD4USB

PAPOUCH
 AD4ETH - Ethernet measurement module

Código: AD4ETH_U_1

Analog measurement module AD4ETH is a four input A/D converter allowing you to measure up to four analogue signals 0-10V or 0(4)-20mA. Measured-out values can be viewed via a WEB interface, AD4ETH also supports TCP, SNMP, Modbus and many other protocols.
  • Four analogue inputs for voltage or current
  • Each channel can have different range (upon request)
  • Measuring range split into 10 000 pieces
  • Mesuring rate: twice in a second for each channel
  • Communication via Ethernet (LAN computer network)
  • Wide power supply voltage range: 7 - 30 V DC
  • Measuring is based on a single multiplexed 16 bit sigma-delta A/D converter
  • SNMP, MODBUS TCP, TCP (Spinel), UDP (Spinel), HTTP GET, HTTP POST (SOAP)
  • Internal WEB server
  • WAP pages for mobile view
  • Measured data in XML format for easy processing in your own application
  • AD4ETH supports sending the data in XML WEB service format by SOAP protocol
  • A/D converter can automatically send the measurements to your server in an HTTP GET request body.
  • E-mail notifications when a preset thresholds are exceeded.
  • Real units calculation functions - you can see the values as a pressure, height, distance, temperature etc.
  • Measurement software for windows as a free

AD4ETH

PAPOUCH
 TDS - Industrial thermometer

Código: TDS_THERM

TDS thermometer can display temperature measured by TQS3 thermometers, that communicate via RS485 line and can be up to 1200m away from it. Temperature is displayed on a 7-segment LED display. In this way you can read-out up to three temperatures in diffe
    null

TDS

PAPOUCH
 TQS3 M - RS485 Thermometer with the probe on a cable

Código: TQS3_M

TQS3 M Thermometer has been discontinued. As a replacement you can use THT2 which is fully compatible product. As a succesor to the TQS3 M, THT2 has a detachable sensor of various lengths, higher range of power voltage and a possibility to connect tempera
    null

TQS3 M

PAPOUCH
 Communication options and internal website of anemometer.

Código: WINDETH_EU

WindETH is an Ethernet anemometer, which is able to measure wind speed and direction. It is connected directly to a computer network (Ethernet). Current measurements are also available via internal WEB interface or various formats like HTTP GET, XML, MODB
    null

WindETH

PAPOUCH
 tme-multi-top-side

Código: TME_MULTI_1

A device for measuring temperature and humidity at up to 32 locations. Configuration and preview of all measured values via a website. TME multi is able to send the current values to the server using HTTP GET requests and can also communicate via SNMP and
    null

TME multi

PAPOUCH
 Papago 2TH ETH- 2x temperature_ humidity and dew point with Ethernet

Código: PGO_2TH_E_1

Ethernet interface with PoE power supply for two combined sensors. It measures only temperature or temperature, humidity and dew point. Temperatures measured in the range from -55 to +125 °C.
    null

Papago 2TH ETH

PAPOUCH
 TH2E with sensor (the sensor must be ordered separately!)

Código: TH2E_C_EU

TH2E is a Thermometer and Hygrometer that can calculate a dew point. It can store measured-out values into its internal memory, send the measured-out values to your server, send e-mails when a threshold is exceeded, TH2E remembers extremes and it has an i
    null

TH2E

PAPOUCH
 TME with a DIN rail holder.

Código: TME_C_EU

TME is a Thermometer with direct output to Ethernet (IP Thermometer), Measuring range is -55°C to +125°C.
    null

TME

PAPOUCH
 TMU - USB thermometer

Código: TMU_C_1

TMU is a simple thermometer with a USB interface. The thermometer uses the USB interface for communication and also as a power source. It measures temperatures from –55 °C to +125 °C. The communication utilizes a simple ASCII protocol. Temperature values
  • USB thermometer
  • Temperature measurement in range from -55°C to +125°C, 0,1°C resolution
  • Sensor connected to a silicon cable with high temperature resistance.
  • Temperature data in ASCII format
  • No numerical conversion of temperature values is necessary
  • Communication over the USB interface
  • Powered from USB as well
  • DIN rail mount available
  • Optionally, a cable up to 20 meters long
  • Different workmanship as requested

TMU

PAPOUCH
 TME PoE - PoE powered ethernet thermometer

Código: TME_POE_1

TME PoE is a PoE powered ethernet Thermometer. It complies with IEEE 802.3af standard. Thanks to that there are no additional power units needed. TME PoE comes out of TME, other than power circuits and internal hardware layout the thermometers have the ve
    null

TME PoE

PAPOUCH
 Papago TH 2DI DO ETH- Environment monitor

Código: PGO_TH2DIDO_E_1

PAPAGO TH 2DI DO is used as an environment monior – it measures temperature, humidity and dew point. It also has two contact inputs to connect either contact or a pulse output and a relay.
    null

Papago TH 2DI DO ETH

PAPOUCH
 papago-2tc-thermocouple-k-connectors

Código: PAPAGO_2TC_ETH_1

Thermometer for thermocouples of type K with two inputs and Ethernet interface with PoE. The accuracy depends on the thermocouple. Measuring range -50 to +1350 °C.
    null

Papago 2TC ETH
